Dartmoor 5 Eco


The unfussy traditionally styled and Defra approved Dean Stoves Dartmoor 5 Eco comes in either a wood burning only model or, for not a lot more money, a multi fuel version with riddler grate and ash pan. As you'd expect from this established British manufacturer the hand built Dartmoor 5 Eco is exceptionally well made. Even the premium quality cast iron door has been cast in Britain and you can''t always say that for other 'British' stoves. Fifty years of stove making expertise is not only clearly in evidence in the Dartmoor 5's high construction standards but also in its outstanding performance.

With a highly controllable 5.0kW heat output and A+ rated 82.1%  efficiency (wood), as well as ultra low emissions that achieve the top Level 5 in the independently verified ClearSkies mark, the best-selling Dartmoor 5 Eco is a compact stove that should certainly be worthy of your consideration. There are three separate combustion air controls, including tertiary air, for precision management of flame height and heat output whether you're burning logs or approved smokeless coal. A powerful air wash helps keep the large glass area clear and robust matt black clamp handle, sturdy feature hinges and heritage leg profile complete the picture of this well-considered and perfectly proportioned traditional stove.

The space-saving Dartmoor 5 Eco also has the distinct advantage of being able to be installed in a brick or stone fireplace opening with just a 50mm air gap at both sides – half the minimum distance usually required. It can also be installed on a 12mm decorative non-comustible hearth and there's also a sweep-through rear flue adaptor option to significantly reduce the space you need at the back of the stove when using the rear flue option. The Dartmoor 5's rear heat shield and integral base protector provide the extra protection that makes all of this possible. Also check out the 135mm (approx 5.5") wider Dartmoor W5 wide bodied 5.0kW with all of the same features and benefits. All Dean Stoves carry a five-year manufacturers warranty.




Heat output  nominal 5.0kW
Output range   3.0kW to 7.0kW depending on fuel load (estimate)
Efficiency                           82.1%% Wood / 80.7% Smokeless Coal
ErP Energy Rating                           A+ Wood / A+ Smokeless Coal
Defra Approved                                  Yes
ClearSkies  Level 5 (the highest Level)
Fuel                                                    Seasoned wood logs / Approved smokeless coal
Airwash                                                Yes
Air Controls

Three separate controls (Primary Boost, Secondary Airwash

and Tertiary Air)

Construction                                          British cast iron door and premium quality steel bodywork
Flue Outlet                                             Top or Rear
Flue Diameter                                    125mm  / 5"
Grate Type

Wood burner has flat bed / MF model has multi fuel          riddle grate with ash pan

Guarantee                                              5 Years
Maximum Log Length                         280mm (11") x 100mm (4") diameter
Standard Colour                          Matt Black
Optional Finishes                            8 designer colours including Grey, Charcoal, Champagne and Mushroom
Options                                        Wood burning or multi fuel model options
Stainless steel handle
                                                    Retro fit multi fuel kit (for wood burning only model)
                                                    Back Box – space saving 180mm deep rear flue adaptor
Weight                                              N/A
Air Vent Required                                Not usually in pre-2008 homes (Subject to Building Regs)
Suitable for 12mm hearth                       Yes
Direct External Air Inlet (DEAS)         No
Overall Dimensions mm                       H540  W430  D315 (with handle 375)
Combustible Distances mm                   Sides 550  Rear 150



Dean Stoves Dartmoor 5 Eco Download Files:

Dartmoor 5 Eco Operational Instructions

Dean Stoves Brochure
